WELCOME TO SHANGHAI AIYIA

The company adheres to the guiding ideology of "quality-oriented, customer first"

and fully implements the ISO9001 quality management system throughout the entire production cycle from product signing, production to delivery and use, and wholeheartedly provides high-quality products to every user.

HOT PRODUCTS

MESH SIZE:38.1x38.1MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 13 6.0/5.0 38.1x38.1 1220x4000 6 0.68 1220x3660 15 6.1/5.0 38.1x38.1 1220x4000 7 0.65 20 6.2/5.0 38.1...

MESH SIZE:40x40MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 25 6.4/5.0 40x40 1007x4047 12.3 0.67 30 6.6/5.0 40x40 1007x4047 14.6 0.67 1247x4047 40 7.0/5.0 40x40 ...

MESH SIZE:50x50 MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 12 6.0/5.0 50x50 1906x4012 4.8 0.82 13 6.0/5.0 50x50 1215x4115 6 0.82 DIAMOND 15 6.2/5.0 50.8x50.8 12...

MESH SIZE:83x83MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 25 6.5/5.0 83.3x83.3 1007x4007 5.8 0.84 40 7.0/5.0 83.3x83.3 1007x4007 9.5 0.84 1507x4088

MICRO MESH SIZE:12.7x12.7/38.1x38.1MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 30 7.5&4.5/5.0 12.7x12.7/38.1x38.1 1220x3660 22 0.3

MICRO MESH SIZE:13x13/40x40MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 22 6.4&4.5/5.0 13x13/40x40 1527x4047 14.3 0.3 25 6.5&4.5/5.0 13x13/40x40 1247x4047 15.2 0.3 30 7.0&4....

MINI MESH SIZE:19x19/38x38MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 25 6.4/5.0 19.05x19.05/38.1x38.1 1220x4000 16.8 0.4 30 6.5/5.0 19.05x19.05/38.1x38.1 1220x3660 17.5 0...

MINI MESH SIZE:20x20/40x40MM

2025-03-13

HIGHT(MM) BEARING BAR THICKNESS(TOP/BOTTOM) MESH SIZE(MM) STANDARD PANEL SIZE AVAILABLE(MM) APPROX. WEIGHT(KG/M²) OPEN RATE(%) LOAD DEFLECTION TABLE 14 6.4/5.0 20x20/40x40 1247x4047 10.5 0.42 22 6.4/5.0 20x20/40x40 1527x4047 15.2 0.42 30 6.5/5.0 20x2...

NEWS & SERVICES
KNOWLEDGE

Through our maintenance and service, we provide you with reliable technical support and understand the difference between various products.

GET A QUICK QUOTE
Contact us for design assistance, free quote, and expert advice today. Your inquiry will be replied within 12 working hours, and we respect your privacy.
